This high-quality wood-burning stove will heat your home beautifully. Thanks to its elegant and modern design, this stove blends seamlessly into any room. It
features three-sided glass and a removable ash pan.
The three fireproof glass panels in the firebox create the impression of a panoramic fireplace.
The design of Teba stoves allows for precise temperature control and easy combustion and ash removal.
The state-of-the-art primary and secondary air control system gives the user instant control over the fire intensity.
Several pipes are integrated into the rear of the combustion chamber to heat the air.
Air circulation draws in cold air from below through these pipes, where it is heated. The heated air then travels through the pipes above the combustion chamber, through the front grille of the stove, and is distributed throughout the room.
An external air supply connection is located at the rear of the stove. This connection draws in cold room air or, if using an external air supply, draws in fresh air and releases it into the room.
Technical Data:
– Overall dimensions: Height 97 cm, Width 61 cm, Depth 49 cm
– Combustion chamber: Height 42 cm, Width 46 cm, Depth 33 cm
– Flue pipe diameter: Ø 150 mm
– Weight: 85 kg
– Color: Black
– Minimum distance to combustible materials from the side: 150 cm
– Minimum distance to combustible materials from the front: 150 cm
– Minimum distance to combustible materials from the rear: 20 cm
– 9 kW nominal output
– 4 kW – 10 kW heat output range
– Efficiency: 85% –
Flue gas temperature: 175°C
– Flue gas mass flow: 8.1 g/s
– Dust emission at 13% O2: 35 mg/Nm³
– CO emission at 13% O2: 1247 mg/Nm³
– NOx emission at 13% O2: 74 mg/
Nm³ CxHy emission at 13% O2: 105 mg/Nm3
– Minimum draft: 12 Pa
– Energy efficiency class: A
– Suitable fuels: firewood, wood briquettes
– Complies with the German Federal Immission Control Act (BImSchV) Stage 2 and the Austrian Federal Constitutional Law (15a-B-VG).
– Complies with the requirements of the Building Regulations (BStV) of the cities of Munich, Regensburg, and Stuttgart, and the Building Regulations (FBStVO) of the city of Aachen
. – Complies with the Swiss Air Pollution Control Ordinance.
– Type 2 construction – Multiple flue connections to the same chimney are not permitted.
– Tested according to DIN EN 13240:2001.
Delivery is by freight carrier, curbside delivery.
