Description
Item description
- 600W 48V – Hub motor – maintenance-free
- New, powerful hydraulic brakes as standard equipment in 2024
- New Comfort Display as standard equipment in 2024
- Multilayer swingarm with double central damper
- Road legal up to 20 km/h
If the Revoluzzer needs to be transported or is not currently in use, it can be folded up in just a few seconds with two simple steps to save space.
The Revoluzzer 4.0 comes standard with large 40 cm diameter tires. The comfort suspension at the front and rear completes the riding experience.
Hydraulic brakes, which are only offered as an extra charge by some other manufacturers, are already fitted as standard here – these allow for significantly simplified brake adjustment, as well as better braking performance.
The new, highly efficient 600W hub motor delivers significantly more power and torque at 48V than conventional DC motors with chain drive. Our smooth-running scooter rolls almost without resistance even without power, resulting in greater range, near-silent operation, and comfortable riding dynamics.
Many different battery options available! Simply disconnect the plug and remove the battery.
Now with the large display as standard. It shows you battery voltage, speed, and distance traveled at a glance, without you having to switch between screens.
The Revoluzzer is street legal within the EU. The corresponding document is included with the vehicle.
Images show models with optional equipment. Please always refer to the scope of delivery.
The image may differ due to model changes; color variations are possible.
Details
| Frame material | Steel |
| Handlebar material | Steel |
| Handlebar grip material | rubber |
| Material of tread surface | Wood |
| Wheel material | rubber |
| Ball bearing material | Steel |
| Mudguard material | Steel |
| Speed ​​control | throttle grip |
| Top speed | 20.00 km/h |
| Engine performance | 600W W |
| Engine details | brushless, maintenance-free |
| starter | ignition switch |
| Drive type | Hub drive |
| Battery details | maintenance-free |
| Battery charging cycles | 350 |
| Battery range | 25.00 km |
| Battery charging time | 6.00 hours |
| Battery type | Lead-acid/Gel battery |
| Type of power supply | Battery (replaceable) |
| Battery/accumulator technology | Lead-acid gel battery |
| Number of batteries required | 1 pc. |
| Battery capacity | 12000.00 mAh |
| Number of batteries | 1 pc. |
| Battery voltage | 48.00 V |
| Type of wheels | Tubular tires |
| Number of wheels | 2 pcs. |
| Climbing ability in percent | 15.00% |
| suspension | Front suspension fork, rear shock absorber |
| Suspension details | shock absorbers |
| Surface finish | non-slip, weather-resistant |
| Characteristics | Height-adjustable, foldable sallet |
| Front brake type | disc brake |
| Front brake design | hydraulic brake system |
| Rear brake type | disc brake |
| Rear brake design | hydraulic brake system |
| Details Handles | non-slip, weather-resistant |
| Intended use | Road traffic |
| Level | Beginners Advanced |
| Display Cockpit | Speed, range, battery level indicator, turn signal direction |
| Scooter lighting | Available at the front and rear |
| Type of light source front | LED |
| Type of rear light source | LED |
| reflectors | available |
| Stand | Side stand with stand switch |
| equipment | Lights, side stand , horn, mudguards, display with odometer, 2 mirrors , charger |
| Saddle cover material | faux leather |
| Saddle features | removable padding |
| Wide saddle | 25.00 cm |
| Saddle length | 27.00 cm |
| Seating position | upright |
| Patterned tread surface | solid color with anti-slip sticker |
| Height of tread surface | 1.20 cm |
| Thickness of tread surface | 12.00 mm |
| Seat height | 6.5 |
| Wheel diameter | 40 cm mm |
| Wheel diameter in inches | 10″ |
| Wide wheels | 80 mm |
| Scooter weight | 41.00 kg |
| Assembly instructions | The scooter is partially assembled. |
| Age recommendation | Ages 15 and up |
| Maximum user weight | 110.00 kg |
| Area of ​​use | within the German Road Traffic Licensing Regulations (StVZO) |
| Required driver’s license | AM |
| Legal obligations | License plate requirement, insurance requirement |
| Special regulation | This item is accompanied by an EU Certificate of Conformity (COC) in English. |
| Still to be assembled | Handlebars, mirrors, saddle, seat, battery |
| Languages ​​Operating/Assembly Instructions | German |
| Warning notices | Please read the instruction manual before use! |
| Ordering information | The scooter is almost fully assembled. |
| Driver’s seat available | The scooter has a driver’s seat. |
| WEEE Reg. No. DE | 90565518 |
