Diesel generator, 12000W emergency power generator, 400V/230V, 06273

Diesel Generator 12000,
12.5 kW Diesel Engine with Electric Start, 12 V / 230 V / 400 V, Soundproofed Generator.

The 12000 diesel generator provides a reliable power supply for the most demanding applications. This high-quality, extremely powerful, soundproofed unit delivers the necessary energy to reliably and safely power machinery and equipment during power outages and in remote locations. Its synchronous generator, combined with the smooth-running, robust diesel engine, provides a continuous output of up to 9500 watts. Thanks to the electric starter with ignition key, it can be started conveniently and easily secured against unauthorized use. The generator’s selector switch allows operation at either 230 V or 400 V. With two 230 V Schuko sockets, a CEE 16A 400 V socket, and a 12 V socket with adapter cable and battery clamps, this generator is equipped for virtually any application. The automatic voltage regulator (AVR) protects connected devices by ensuring a stable output voltage, quickly compensating for load changes, and reducing undervoltages and overvoltages. An electric starter and decompression lever ensure effortless starting of the diesel engine. Additionally, the overload switch provides the necessary operational safety. With a 30-liter capacity, the large fuel tank offers ample reserves for extended use, which the durable, double-bearing crankshaft easily handles. A fuel gauge keeps the fuel level constantly visible, and a low-oil shutdown protects against engine damage. Push handles and high-quality wheels make the generator easy to transport.

Product advantages:
– Smooth-running, economical 12000 diesel synchronous generator
– Convenient electric start, powerful 12.5 kW diesel engine
– Powerful air-cooled 762 cc single-cylinder diesel engine, crankshaft supported on both sides
– Low oil level protection to prevent engine damage
– Electric starter and AVR regulation for stable output power with voltmeter
– Switchable between 230 V Schuko socket or 400 V CEE-16 socket, as well as 1 x 12 V DC
– Overload switch for device safety
– Large 30-liter tank with fuel gauge
– High-quality wheels and push handle for easy transport

Technical data:
Generator type: Synchronous
Frequency: 50 Hz
Diesel engine: 762 cm³ / 1-cylinder, four-stroke, air-cooled
Engine speed: 3000 rpm
Max. engine power: 12.5 kW
Continuous power 12V DC: 100 W
Continuous power (S1) at 230 V: 3200 W
continuous power (S1) at 400 V: 9500 W
max. power (S2) at 230 V: 3500 W
max. power (S2) at 400 V: 10000 W
Rated current 12 V: 8.3 A DC
Rated current 230 V / 400 V: 18.3 A
Tank capacity: 30 L diesel.
Runtime at full load: 10 h.
Sound power level LwA: 96 dB(A).
Sound level (7m): 75 dB(A).
Dimensions: 1180 x 675 x 870 mm.
Weight approx.: 200 kg.

Scope of delivery:
1 x diesel generator 12000
, 1 x tool and accessory kit.

Notes:
– Delivery does not include operating fluids (oil and diesel). Fill with oil and diesel before first use.
– Shipping via freight carrier; therefore, please provide us with a telephone number where you can be reached daily.
– Delivery time, depending on the region, is 2-5 business days after receipt of payment.
– No shipping to parcel lockers or islands.
