Sunstone Power’s AGM battery is suitable for UPS/UPS backup power supply for floating charge. It is a type of VRLA (valve-regulated lead-acid battery), which means that it is fully enclosed and maintenance-free, does not cause pollution, and has a low risk of safety incidents. Their operating temperature range is wide and their high-current discharge performance is excellent. To ensure a long service life of 10 years, the plates are made of a sophisticated alloy that provides better corrosion protection.
The AGM battery can be used in scenarios such as network equipment, data centers, emergency lighting systems, security and surveillance systems. It can also be used as an alternative to gel batteries in solar systems. Here is the number of cycles for your information: It reaches 500 cycles at a depth of discharge of 50%. Thanks to its robust construction, it can be used both vertically and horizontally on the ground.
Note: UPS battery is not suitable for use as a starting battery or power battery. If you want to use the battery like this for a long time, the battery life will be shortened quickly.
Technical data
| Weight |
21Kg |
| Size (LxWxH) |
350x168x178mm |
| Nominal voltage |
12V (6 cells) |
| Nominal Capacity |
68.5AH (20pcs, 1.80V/cell, 25°C)
65.0AH (10pcs, 1.80V/cell, 25°C)
55.3AH (5pcs, 1.75V/cell, 25°C)
39.0AH (1pcs, 1.60V/cell, 25°C) |
| Terminal |
M6 |
| Housing Material |
ABS |
| Max. discharge current |
650A (5S) |
| Internal resistance |
Approx. 6.8mΩ |
| Charging mode |
Discharge Operating Temperature: -15~50°C
Charging Operating Temperature: 0~40°C
Storage Temperature: -15~40°C |
Nominal operating
temperature range |
25 ± 3°C |
| Cycle Consumption |
14.4~14.8V (25°C) temperature coefficient -30mV/°C
initial charging current less than 0.3C |
Details
Product details
| Life cycles |
500 |
| Suitable for |
UPS, lighting, emergency power |
| Model name |
ML12-65 |
| Features |
Maintenance-free |
| Features |
Spare battery |
| Color |
grey |
| Number of batteries |
1 pc. |
Technical data
| Capacity |
65000 mAh |
| Voltage |
12 V |
| Charging voltage maximum |
14.80 V |
| Charging current maximum |
19500.00 mA |
| Ambient temperature minimum |
-15 °C |
| Ambient temperature maximum |
50 °C |
| Output voltage |
12 V |
| Technology |
Lead AGM |
| Battery/rechargeable battery technology |
Lead AGM |
| WEEE-Reg.-Nr. DE |
31686483 |
Power supply
| Battery capacity |
65000.00 mAh |
| Battery capacity in Ah |
65.00 Ah |
Dimensions & Weight
| Weight |
21000.00 g |
Remarks
| Manufacturer’s warranty |
2 years |
| Product Notes |
All information is approximate |
